Fume Extraction System
Fume Extraction System
The Fume Extraction System is designed to capture, filter, and remove hazardous fumes, smoke, and fine particulate matter at the source, ensuring a safe and compliant industrial working environment. It effectively controls airborne contaminants generated during welding, cutting, soldering, melting, and chemical processes.
Airflow Capacity1000 to 100,000 CFM
Filtration Efficiency99.9%
Operating TemperatureUp to 80°C
Working Principle
Contaminated air is captured at the source using hoods, extraction arms, or enclosures. The air passes through multi-stage filters where fumes and particulates are removed, and clean air is either recirculated or safely exhausted outside.
Dust-laden air / gasClean air
Technical Specifications 13 PARAMETERS
| System Type | Dry fume extraction with spark arrestor and filtration unit |
|---|---|
| Airflow Capacity | 1000 to 100,000 CFM (can be customized based on process requirement) |
| Capture Method | Extraction arm / Hood / Enclosure |
| Filtration Stages | Pre-filter + Fine filter + HEPA (Optional) |
| Filtration Efficiency | 99.9% (HEPA up to 0.5 micron) |
| Filter Media | Polyester / PTFE / Activated Carbon (Optional) |
| Suitable Contaminants | Welding fumes, smoke, oil mist, chemical vapors |
| Fan Type | Centrifugal blower |
| Noise Level | ≤ 85 dB(A) |
| Construction Material | Mild Steel / Stainless Steel |
| Operating Temperature | Up to 80°C |
| Control System | Manual / VFD / PLC (Optional) |
| Power Supply | 415 V / 50 Hz / 3 Phase |
Applications
- Welding & Fabrication Shops
- Foundries & Metal Melting Areas
- Laser / Plasma / Gas Cutting
- Electronics Soldering
- Chemical & Pharmaceutical Industries
