Dust Extraction & Collection System
Envelope Type
Dust CollectorThe Envelope Type Dust Collection System is a high-efficiency dry dust filtration system designed to capture fine and medium particulate matter from industrial processes. It uses envelope-shaped fabric filter elements, providing a large filtration area in a compact footprint. The system is suitable for continuous operation and ensures compliance with environmental emission norms. Designed for applications involving high dust loading and low to medium temperature gases.
Air Handling Capacity1,000 to 100,000 CFM / m³/hr
Filtration Efficiency99.5% to 99.9%
Operating TemperatureUp to 120°C
Working Principle
Dust-laden air / gasClean air
Technical Specifications 9 PARAMETERS
| Air Handling Capacity | 1,000 to 100,000 CFM / m³/hr (can be customized on the basis of process requirement) |
|---|---|
| Filtration Efficiency | 99.5% to 99.9% |
| Outlet Emission | < 20 mg/Nm³ |
| Filter Media | Polyester / PP / Acrylic / Nomex / PTFE |
| Operating Temperature | Up to 120°C (standard), up to 220°C (high-temp) |
| Cleaning System | Pulse Jet / Reverse Air |
| Pressure Drop | 120 to 180 mmWC |
| Construction | MS (painted) / SS 304 / SS 316 |
| Hopper | 60° sloped with dust discharge arrangement |
Applications
- Cement & Building Material Plants
- Foundry & Metal Casting Industries
- Boiler & Thermal Power Plants
- Chemical & Pharmaceutical Industries
- Food, Grain & Spice Processing Units
- Woodworking, MDF & Laminate Plants
- Mineral Processing & Mining
- Steel, Power & Refractory Industries
